CNC Lathe
Offer
- stock-no.:
- 0305014
- type of machine:
- CNC Lathe
- make:
- EMCO
- model:
- Turn 340
- year of manufacture:
- 2000
- type of control:
- CNC
- country of origin:
- Austria
- freight basis:
- EXW, free on truck unpacked
- storage location:
- Leipzig 5
- delivery time:
- by arrangement
- price:
- on request
technical details
- turning diameter over bed:
- 340 mm
- turning dia. over face-slide:
- 158 mm
- turning length:
- 300 mm
- facing movement (x-axis):
- 300 mm
- longitudinal traverse (z-axis):
- 300 mm
- control:
- Siemens 810T
- revolution per minute:
- 60 - 4.000 U/min
- max. torque on the spindle:
- 106 - 145 Nm
- external spindle dia. in forward position:
- 80 mm
- feed motor:
- 8500 N
- rapid motion - x-axis:
- 6 m/min
- tool turret - number of stations:
- 8
- tailstock adjustment:
- 120 mm
- Main spindle capacity:
- 11/15 kW
- operating hours - idle run:
- h
- electrics - voltage/frequency:
- 380/50 V/Hz
- total power requirement:
- 20 KVA
- Weight approx.:
- t
- dimension machine approx.LxWxH:
- m
