Center LatheCenter Lathe NILES-ZERBST DLZ 630III

Center Lathe NILES-ZERBST DLZ 630IIICenter Lathe NILES-ZERBST DLZ 630IIICenter Lathe NILES-ZERBST DLZ 630IIICenter Lathe NILES-ZERBST DLZ 630IIICenter Lathe NILES-ZERBST DLZ 630III

Offer

stock-no.:
0303061
type of machine:
Center Lathe
make:
NILES-ZERBST
model:
DLZ 630III
year of manufacture:
1960
type of control:
conventional
country of origin:
Germany
freight basis:
Ex-Location
storage location:
GOG Bitterfeld - Bestand
delivery time:
immediately
price:
on request

technical details

turning diameter over bed:
630 mm
turning diameter over support:
320 mm
turning length:
2800 mm
centre distance:
2800 mm
turning dia. in gap:
700 mm
length of gap:
450 mm
spindle bore of work spindle:
70 mm
center height measured in bed:
mm
support travel z-axis:
mm
range of revolution per miute:
U/min
rapid travel - longitudinal/face:
m/min
feed::
mm/U
tailstock quill taper MT:
tailstock quill adjustment::
mm
total power requirement:
kW
weight of the machine ca.:
4,4 t
dimension machine approx.LxWxH:
4,7 x 1,5 x 1,5 m

additional information

Thread cutting possible
Accessories:
4-jaw chuck
various tips
Gear wheels
Jaws and small parts
