Facing LatheFacing Lathe WMW ZERBST DP 2-S

Facing Lathe WMW ZERBST DP 2-SFacing Lathe WMW ZERBST DP 2-SFacing Lathe WMW ZERBST DP 2-SFacing Lathe WMW ZERBST DP 2-SFacing Lathe WMW ZERBST DP 2-SFacing Lathe WMW ZERBST DP 2-SFacing Lathe WMW ZERBST DP 2-SFacing Lathe WMW ZERBST DP 2-SFacing Lathe WMW ZERBST DP 2-SFacing Lathe WMW ZERBST DP 2-S

Offer

stock-no.:
0300212
type of machine:
Facing Lathe
make:
WMW ZERBST
type:
DP 2-S
year of manufacture:
1987/2019
type of control:
conventional
country of origin:
Germany
freight basis:
EXW, free on truck
storage location:
Leipzig 5
delivery time:
3 months after order
price:
on request

technical details

faceplate diameter:
2000 mm
turning diameter over support:
2000 mm
turning length:
2340 mm
center height:
1250 mm
spindle bore:
98 mm
max. workpiece weight between centres:
16000 kg
workpiece weight:
3,8t bei 50mm Abstand t
workpiece weight:
2,0t bei 600mm distance t
total power requirement:
65 kW
weight of the machine ca.:
36 t
space requirement approx.::
variable m

additional information

The machine will be modernized. (electric, electric cabinet, main drive with frequency converter stepless adjustable and 4-axis digital readout system).

axis travel support stand:
- bed slide 1700mm (longitudinal)
- intermediate slider 780mm
- cross slider 640mm
- upper slider 120mm

equipment:
- 1x steady rest dia.740mm
- 1x roll attachment
- 1x grinding device
- 1x four times turning tool holder
- 1x tailstock (can be moved electric)
- 4x floor plates
- turning length of 4000mm via repositioning possible!
