Turret Lathe - Automatic
Offer
- stock-no.:
- 0300132
- type of machine:
- Turret Lathe - Automatic
- make:
- KOVOSVIT MAS
- model:
- MAS A 20 B
- year of manufacture:
- 1983
- type of control:
- conventional
- country of origin:
- Czech Republic
- freight basis:
- EXW, free on truck unpacked
- storage location:
- Leipzig 4
- delivery time:
- immediately
- price:
- on request
technical details
- number of spindles:
- 1
- spindle passage:
- 20 mm
- turning length:
- 350 mm
- turning diameter over bed:
- 240 mm
- revolution per minute:
- 23-4457 U/min
- spindle bore:
- 22 mm
- material length:
- 2000 mm
- voltage:
- 3x380/50Hz V / Hz
- total power requirement:
- 8 kW
- weight of the machine ca.:
- ca. 1,5 t
- space requirements of the machine approx.:
- L:1,84xB:0,9xH:1,8 m
additional information
One Spindle - Cam Controlled Automatic Lathe with bar loader
number of travels: 5 axis
turret support travel longtidudinal 60mm, swing 125mm
turret for for 6 tool taper, temporarily 3 pcs ocuppied
equipment:
collet chuck
tool taper via clamp mounting with bolt
documentation
i.D.
Sorry the machine has been sold already! Here you will find more machines referring to your required category.
