Forging Press - Double ColumnForging Press - Double Column STANKOIMPORT F 1738

Forging Press - Double Column STANKOIMPORT F 1738Forging Press - Double Column STANKOIMPORT F 1738Forging Press - Double Column STANKOIMPORT F 1738Forging Press - Double Column STANKOIMPORT F 1738Forging Press - Double Column STANKOIMPORT F 1738Forging Press - Double Column STANKOIMPORT F 1738

Offer

stock-no.:
0700800
type of machine:
Forging Press - Double Column
make:
STANKOIMPORT
model:
F 1738
year of manufacture:
ca. 1986
type of control:
conventional
country of origin:
Russia
freight basis:
from location,without dismantling
storage location:
Pritzwalk
delivery time:
immediately
price:
on request

technical details

pressure:
650 t
slide stroke:
max. 520 mm
stroke per minute:
minimum = 25 Hübe / min
dayligth:
< 500 mm
Table dimensions:
1000x900 mm
clamping surface ram:
800x800 mm
daylight between the columns:
800 mm
height over floor:
6155 mm
total height:
6655 mm
total power requirement:
90 kW
weight of the machine ca.:
45 t
dimensions::
H: 6,7 x B: 2,5 x T: 1,0 m

additional information

Forging / Screw Friction Press
- mech. forging Press (without ejector)
i.D.
