Machine data
- Machine type
- Band Saw - Automatic - Horizontal
- Manufacturer
- KLAEGER & MUELLER
- Type
- HBA 300G CNC
- Year of manufacture
- 2020
- Control type
- CNC
- Country of origin
- Germany
Technical data
- cutting diameter
- 300 mm
- saw band length
- 3200 mm
- saw band width
- 27 mm
- dimensions of saw-band
- 3660 x 25 x 0,9 mm
- electrical connection
- 400/50 V / Hz.
- total power requirement
- 1,1 kW
- work height max.
- 650 mm
- machine weight approx.
- 960 kg
- cutting speed
- 15 - 95 m/min
- dimension machine approx.LxWxH
- 2,2 x 2,0 x 1,3 m
Additional description
The Klaeger & Müller HBA 300 G CNC is a robust, hydraulically operated CNC horizontal band saw designed for precise and economical cutting of solid materials, tubes, and profiles made of steel, stainless steel, aluminum, and non-ferrous metals. Thanks to its CNC control system, it enables the automatic processing of production batches with high repeatability and productivity.
The machine is equipped with a hydraulic material feed, automatic saw feed, and infinitely variable blade speed adjustment, allowing optimal machining of a wide variety of materials. Its rigid machine construction ensures smooth, low-vibration operation, excellent cutting quality, and extended saw blade life. In addition, the band saw is fitted with a coolant system that improves blade life and ensures clean, accurate cutting surfaces.
The Klaeger & Müller HBA 300 G CNC is particularly suitable for industrial applications in metal fabrication shops, steel construction, toolmaking, mechanical engineering, and serial production.
Terms of storage and delivery
- Freight base
- EXW, free on truck unpacked
- Storage location
- Leipzig 1
- Delivery time
- on request
- Price
Subject to changes and errors in technical details and specifications, as well as prior sale.
